Up to 5 Bluetooth® devices can be paired to the receiver at the same time. You can enjoy audio streaming just by switching the devices with your friends or family.Read More
255 Segment 1.5 Line Text Display
Amazon Alexa Ready
Spotify Ready
Variable Color Illumination
Conformal Coating
3 Preouts 4.0V
Water resistant cone
Full-range Speaker
Polypropylene Injection Cone Woofer
Balanced Dome Tweeter
General Specs | |
| Bluetooth Capable | Yes |
| Number of USB Ports | 1 |
| Satellite Radio Ready | Yes |
| CD Player | Yes |
| Faceplate Style | Detachable |
| Car Stereo Din Size | Single |
| Preamp Voltage | 4 Volts |
FM | |
| Frequency Range | 87.9MHz to 107.9MHz |
| (Frequency step) | (200kHz) |
| Usable Sensitivity | 8.2dBf |
| S/N 30dB | (0.71μV/75Ω） |
| Quieting Sensitivity | 17.2dBf |
| DIN S/N:46dB | (2.0μV/75Ω） |
| Frequency Response(±3.0dB) | 30Hz to 15kHz |
| S/N | 64.0dB(MONO) |
| Stereo Separation | 40dB(1kHz) |
AM | |
| Frequency Range | 530kHz to 1700kHz |
| (Frequency step) | (10kHz) |
| Channel Space Selection | - |
| Usable Sensitivity | 29dBμ (28.2μV) |
| S/N:20dB | - |
CD | |
| Laser Diode | GaAlAs |
| Digital Filter(D/A) | 8 Times OverSampling |
| Spindle Speed | 500 to 200rpm (CLV) |
| Wow & Flutter | Below Measurable Limit |
| Frequency Response | 20Hz to 20kHz(±1dB) |
| Total Harmonic Distortion | 0.02%(1kHz) |
| S/N Ratio (dB) | 99dB(1kHz) |
| Dynamic Range | 92dB |
| Channel Separation | 90dB |
| MP3 Decode | Compliant with MPEG-1/2 Audio Layer-3 |
| WMA Decode | Compliant with WINDOWS MEDIA AUDIO |
| AAC Decode | AAC-LC ".aac" files |
| WAV Decode | - |
USB I/F | |
| USB | USB 1.1 / 2.0 High Speed |
| File System | FAT12 / 16 / 32 |
| Maximum Supply current | DC5V(DC logo) 1.5A |
| MP3 Decode | Compliant with MPEG-1/2 Audio Layer-3 |
| WMA Decode | Compliant with Windows Media Audio |
| AAC Decode | AAC-LC ".aac",".m4a" files |
| WAV Decode | Linear-PCM |
| FLAC Decode | FLAC file (Up to 24bit/96kHz) |
AUX | |
| Frequency Response | 20Hz to 20kHz ±3dB |
Input | |
| Input Maximum Voltage | 1000mV |
| Input Impedence | 30kΩ |
AMP | |
| Maximum Power | 50Wx4 |
| Full Bandwith Power(at less than 1%THD) | 22Wx4 |
Tone | |
| Band1 | 62.5Hz ±9dB |
| Band2 | 100Hz ±9dB |
| Band3 | 160Hz ±9dB |
| Band4 | 250Hz ±9dB |
| Band5 | 400Hz ±9dB |
| Band6 | 630Hz ±9dB |
| Band7 | 1kHz ±9dB |
| Band8 | 1.6kHz ±9dB |
| Band9 | 2.5kHz ±9dB |
| Band10 | 4kHz ±9dB |
| Band11 | 6.3kHz ±9dB |
| Band12 | 10kHz ±9dB |
| Band13 | 16kHz ±9dB |
Bluetooth | |
| Version | Bluetooth 4.2 |
| Frequency Range | 2.402 to 2.480GHz |
| RF Output Power (E.I.R.P.) | +4dBm (MAX), Power Class 2 |
| Maximum Communication range | Line of sight approx.10m(32.8ft) |
| Profile | HFP 1.7.1, SPP, PBA, A2DP, AVRCP 1.6.1 |
General | |
| Preout Level(mV)/Load -Unbalanced | 4000mV/10kΩ |
| Preout Impedance(Ω) | =<600Ω |
| Speaker Impedance(Ω) | 4 to 8Ω |
| Operating voltage | 12V DC car battery |
| Installation Size (W) | 182(mm) 7-3/16(in) |
| (H) | 53(mm) 2-1/16(in) |
| (D) | 155.5(mm) 6-1/8(in) |
| Net Weight (Trim plate and Mounting sleeve: Included) | 1.2(kg) 2.7(lbs) |
