Product Dimensions 2.05"h x 13.96"w x 6.93"d
The NexD2™ full-range technology in the main channels of this amplifier is DSP-controlled and features a reduced loop area design utilizing DirectFET™ outputs for outstanding fidelity, very low noise and exceptional efficiency.Read More
Engineered to deliver reference-grade audio performance in marine environments, every MVi amplifier unites our cutting-edge NexD2™ switching amplifier technology with an integrated, full-featured digital signal processor.
Equipped with our second-generation NexD2™ technology, the MV700/5i is capable of powering a complete marine audio system. It can drive four main speakers with 75 W x 4 @ 4 ohms, while also powering a subwoofer with up to 300W @ 2 ohms. Bridging the main channels transforms it into a very powerful, 3-channel system amplifier with up to 200W x 2 @ 4 ohms on the main channels and 300W @ 2 ohms on the subwoofer channel.
The NexD2™ full-range technology in the main channels of this amplifier is DSP-controlled and features a reduced loop area design utilizing DirectFET™ outputs for outstanding fidelity, very low noise and exceptional efficiency. The subwoofer channel features an optimized low-frequency variant of the NexD2™ technology. The amplifier chassis is a ultra-compact, cast alloy design with marine-grade powder coat finish and corrosion-resistant hardware.
Instead of traditional control knobs and switches, all amplifier adjustments and DSP functionality are configured via a compatible external device (PC, Tablet or Smartphone), with the appropriate JL Audio TüN™ Software application installed.
Power Connector (for 4 AWG wire)
Speaker Output Harnesses (2)
Subwoofer Output Harness
6 ft A/B USB Cable
General Specs | |
| Color | White |
| Depth (in.) | 6.93 |
| Width (in.) | 13.96 |
| Height (in.) | 2.05 |
| Preamp Outputs | 3 |
| Amplifier Class | Class D |
| Amplifier Output (Watts) | 700 |
| Bluetooth Capable | No |
| Amplifier Channels | 5 |
| Manufacturer Warranty | 2 Year |
| Impedance | 2 - 4 Ohms |
| RMS Power Handling (Watts) | 300 |
| Water Resistant | No |
| Shallow Mount | No |
| Digital Input | No |
| Speaker Level Input | No |
| Number Of Outputs | 3 |
| Minimum Impedance Unbridged | 2 Ohm |
| Number Of Inputs | 4 |
| Product Weight (lbs.) | 5.6 |
